DC-950

Cloth Marking Drill With Heater

DC-950
DC-950-1

Cloth Marking Drill With Heater

SM-201L (Tapered Drill with machine: 1.6mm * 2 pcs 2.0 mm * 2 pcs)


Features:
(1)The same type of machine can drill the maximum thickness of the model

Power 120W * In ordering please specify Voltages
Drill Height 200MM(8")
Motor Speed 50Hz/60Hz , 2850/3450 RPM
Net weight 5.5 Kgs/set
Gross weight 27.6 Kgs /4 sets /CTN
Package 4 Sets / CTN:61*45*52 cm
Drills
(Optional)
Tapered Drill Needles: 1.0, 1.2, 1.6, 2.0, 2.5, 3.0, 4.0, 5.0 mm O.D. * 330 mm Length
Hollow Drill Needles: 1.6, 2.0, 2.5, 3.0, 4.0, 5.0 O.D. * 330 mm Length

Laser Liner Marker With Magnetic Holder
Laser Area
Holders are launched on the track and can be re-located according to usage, projector can be adjusted 360 degrees easily, track length can be customized.

Laser Liner Marker With Magnetic Holder

LD-073 , LD-078 , LDX-701


Features:
(1)Very useful while stacking cloth and cutting fabric, can easily help users get the precise work.
(2)Semiconductors are made in Japan and with very good qualities.
(3)Circuit protection devices can significantly extend product life.
(4)Projector can be adjusted 360 degrees easily.

Model LD-073 LD-078 LDX-701
Pattern Line Line Big Cross
Voltage 100-240V/5VDC
* In ordering please specify Voltages
100-240V/5VDC
* In ordering please specify Voltages
100-240V/5VDC
* In ordering please specify Voltages
Visible Distance 3 M 5 M 2-5 M

Optional:Mini-Laser Line Marker( SLD-03、SLD-04、SLD-05), Green Light Laser Line Marker(LD-063G、LD-066G))
